Replacement tank LRA 136L Toyota Land Cruiser Prado 150

The replacement tank LRA is designed for Toyota Land Cruiser Prado 150 GRJ150 and KDJ150 vehicles originally equipped with a dual fuel tank. It replaces the original secondary tank and increases its capacity to 136 liters. This additional capacity allows for carrying more fuel for long-distance travel, tracks, raids, and travel in isolated areas.

Positioned behind the rear axle, this tank retains the standard filler point, standard exhaust, and spare wheel. It is not compatible with vehicles equipped with KDSS suspension or with theTow bar Milford. LRA confirms compatibility with theTow bar Hayman Reece R2872, with removal of the bar and then reinstallation after tank installation. The instructions also indicate the reuse of the original fuel pickup assembly, with modification of the metal tubes according to the instructions. LRA.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Replacement tank
- Capacity: 136 liters
- Vehicle compatibility: Toyota Land Cruiser Prado 150 GRJ150 and KDJ150
- Required configuration: model equipped with a factory-installed dual fuel tank
- Tank replaced: original secondary tank
- Position: behind the rear axle
- Exhaust: standard
- Filling point: standard
- Spare wheel: retained
- Fuel system: original fuel sample taken and modified according to instructions LRA
- Incompatibilities: KDSS suspension and Tow bar Milford
- Special compatibility: Tow bar Hayman Reece R2872, with removal and then refitting of the bar after installation
- Estimated assembly time: 3 hours
- Made in Australia

Compatibility:

- Toyota Land Cruiser Prado GRJ150 petrol, estate, 4-wheel drive: 2009 to 2023
- Toyota Land Cruiser Prado KDJ150 diesel, station wagon, 4-wheel drive: 2009 to 2013
- Toyota Land Cruiser Prado KDJ150 diesel, station wagon, 4-wheel drive: 2015 to 2023
- Toyota Land Cruiser Prado KDJ150 petrol, estate, 4-wheel drive: 2014
