Additional tank LRA 95L Toyota Land Cruiser HZJ75 FZJ75 HZJ78 FZJ78

The auxiliary tank LRA is designed for Toyota Land Cruiser HZJ75, FZJ75, HZJ78 and FZJ78 in Troopy 4-wheel drive version. He adds a fuel capacity of 95 litres and can be fitted to models equipped with a single or dual original fuel tank. This additional reserve allows for increased fuel capacity for travel, off-road excursions, expeditions, and journeys in remote areas.

Positioned on the left side of the driveshaft, this tank uses a dual filler neck. The exhaust system must be modified with a muffler change, which is not included in the kit. The spare tire remains in place. This setup allows for the addition of auxiliary capacity without relocating the spare tire, while maintaining a configuration suitable for expedition and off-road vehicles.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Auxiliary tank
- Capacity: 95 liters
- Vehicle compatibility: Toyota Land Cruiser HZJ75, FZJ75, HZJ78 and FZJ78
- Bodywork: Troopy
- Transmission: 4-wheel drive
- System requirements: compatible with original single or dual tank models
- Position: left side of the driveshaft
- Exhaust: modification required
- Exhaust modification: muffler replacement, not included in the kit
- Filling point: double filling point
- Spare wheel: retained
- Estimated assembly time: 7.5 hours
- Shipping dimensions: 105 x 70 x 60 cm
- Shipping weight: 53 kg
- Made in Australia

Compatibility:

Toyota Land Cruiser FZJ75 petrol, Troopy, 4-wheel drive: 1992 to 1999
Toyota Land Cruiser FZJ78 petrol, Troopy, 4-wheel drive: 2000 to 2005
Toyota Land Cruiser HZJ75 diesel, Troopy, 4-wheel drive: 1992 to 1999
Toyota Land Cruiser HZJ78 diesel, Troopy, 4-wheel drive: 1999 to 2006
