Replacement tank LRA 130L Toyota Hilux 65 Petrol / Diesel

The replacement tank LRA is designed for the Toyota Hilux 65 Series RN/LN, in Double Cabpetrol or diesel, 4-wheel drive, from 1983 to 1988. It replaces the original tank and increases the fuel capacity to 130 litres. This additional capacity allows for carrying more fuel for long-distance journeys, tracks, travel and professional uses in remote areas.

Positioned on the right side of the driveshaft, this tank retains the standard filler neck and spare tire. The exhaust system must be modified, including replacing the muffler, which is not included in the kit. The instructions specify that the original fuel gauge unit is reused and that the float arm must be adjusted to maintain an accurate fuel level reading.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Replacement tank
- Capacity: 130 liters
- Vehicle compatibility: Toyota Hilux 65 Series RN/LN
- Compatible years: 1983 to 1988
- Compatible engine types: petrol and diesel
- Bodywork: Double Cabine
- Transmission: 4-wheel drive
- Position: right side of the drive shaft
- Exhaust: modification required
- Exhaust modification: change of the muffler, not supplied in the kit
- Filling point: standard
- Spare wheel: retained
- Gauge: original gauge unit reused
- Modification indicated: adjustment of the float arm according to the instructions LRA
- Special mounting feature: the front shackle on the driver's side may require cutting to the length of the shackle bolt nut
- Estimated assembly time: 3 hours
- Made in Australia
