Additional tank LRA 150L Toyota Land Cruiser FZJ105

The auxiliary tank LRA is designed for Toyota Land Cruiser FZJ105 petrol Wagon 4WD body, from 1998 to 2002. With its capacity to 150 litersIt allows you to increase the amount of fuel carried for journeys, tracks, raids and travel in isolated areas, while retaining the original main tank.

This tank is located behind the rear axle on rigid axle models originally equipped with a single fuel tank. Installation requires modifying the original filler neck to accommodate a dual-filler system. Fuel is transferred to the main tank by an electric pump, controlled by a switch with a fuel gauge. LRA-PG210 installed in the passenger compartment. The spare wheel must be moved.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Auxiliary tank
- Capacity: 150 liters
- Vehicle compatibility: Toyota Land Cruiser FZJ105
- Compatible years: 1998 to 2002
- Compatible engine type: Petrol
- Body type: Wagon
- Transmission: 4WD
- Required configuration: Rigid deck model with original single tank only
- Position: Behind the rear bridge
- Exhaust: Standard
- Filling point: Double filling point
- Transfer pump: Electric pump included
- Gauge: Switch with gauge LRA-PG210 supplied
- Spare wheel: To be moved
- Estimated assembly time: 5 hours
- Made in Australia
