Additional tank LRA 160L Toyota Landcruiser HDJ100

The auxiliary tank LRA is designed for Toyota Land Cruiser HDJ100 from 2000 to 2007, in diesel version, station wagon, 4-wheel drive, with independent front suspension and original single tank. It is installed under the rear of the vehicle and adds a fuel capacity of 160 litres. This additional reserve allows for increased fuel capacity for long-distance journeys, raids, tracks and travel in isolated areas.

This tank operates with an electric transfer pump that sends fuel to the original main tank. The original filler neck must be modified to accommodate a new dual-filler system. A control unit with a fuel gauge is integrated into a suitable location within the passenger compartment, indicating pump operation and the auxiliary tank's fuel level. The spare tire must be relocated.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Auxiliary tank
- Capacity: 160 liters
- Vehicle compatibility: Toyota Land Cruiser HDJ100
- Compatible years: 2000 to 2007
- Compatible engine type: diesel
- Body style: station wagon
- Transmission: 4-wheel drive
- Required configuration: model with independent front suspension and original single fuel tank
- Position: under the rear of the vehicle / behind the rear axle
- Exhaust: standard
- Filling point: double filling point
- Filling modification: original filling neck to be modified
- Transfer pump: yes, electric pump to the original main tank
- Gauge / control: control with gauge LRA integrated into the passenger compartment
- Spare wheel: relocation required
- Estimated assembly time: 5 hours
- Made in Australia
