Additional tank LRA 75L Toyota Land Cruiser Prado RZJ95R

The auxiliary tank LRA is designed for the Toyota Land Cruiser Prado RZJ95R petrol, estate body, 4-wheel drive, produced from 1997 to 2001. He adds a fuel capacity of 75 litersThis additional reserve allows for increased fuel capacity for journeys, off-road tracks, raids, and travel in isolated areas.

Positioned on the left side of the driveshaft, this tank is intended only for models originally equipped with a single fuel tank. It operates with an electric transfer pump that sends fuel to the main tank. The original filler neck is replaced with a dual filler neck. A control with a fuel gauge is included. LRA It is installed in the passenger compartment to indicate the operation of the pump and the level of the auxiliary tank. The spare wheel remains in place.

Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.

Technical specifications:

- Type: Auxiliary tank
- Capacity: 75 liters
- Vehicle compatibility: Toyota Land Cruiser Prado RZJ95R
- Compatible years: 1997 to 2001
- Compatible engine type: petrol
- Body style: station wagon
- Transmission: 4-wheel drive
- Required configuration: model with original single tank only
- Position: left side of the driveshaft
- Location: in front of the rear axle, left side of the vehicle
- Exhaust: standard
- Filling point: double filling point
- Transfer pump: electric pump to the main tank
- Gauge / control: control with gauge LRA integrated into the passenger compartment
- Spare wheel: retained
- Estimated assembly time: 5 hours
- Made in Australia
